Connecting measurement for

HAKE-SPECIAL sprayballs

DIN 11850, Row 1 • Material HC22 (2.4602)

Overview of the connecting dimension
(indicated in mm)
DN A B C D E H B
(available with IG)
8 - 8.2 - 20 15 32.5 AG 1/8"
10 9 12.2 2.2 24 17 37.5 IG 1/8"
15 9 18.2 2.2 30 18 42 IG 1/4" ; IG 3/8"
20 9 22.2 2.5 40 21 53 IG 1/2"
25 18 28.2 2.8 64 35 90 IG 1"
32 18 34.2 2.8 64 35 90 IG 1"
40 18 40.3 2.8 64 35 90 IG 1"
